UTM firewall and VPN functions
Valid for all Securepoint firewall models
Firewall-Videos
Wir haben Videos für Sie zusammengestellt, in denen wir Firewall Funktionen beschreiben.
Web interface
| UTM licence | VPN edition | |
|---|---|---|
| Languages | German, English | German, English |
| Accessibility: Mode for colour vision deficiency | yes | yes |
| Dark mode | yes | yes |
| Audit-capable | yes | yes |
| Real-time monitoring functions | yes | yes |
| Configuration management | Multiple configurations on one system | Multiple configurations on one system |
| Triple firmware system for optimum security during upgrades | yes | yes |
| Backup management | Manually, automatically via cloud | Manually, automatically via cloud |
| Local administration | Web user interface, SSH, console via serial connection, monitor + keyboard | Web user interface, SSH, console via serial connection, monitor + keyboard |
| External administration | Unified Security Console (USC) | Unified Security Console (USC) |
| CLI (Command Line Interface) | Console-based management - scripting and remote management possible | Console-based management - scripting and remote management possible |
| Responsive design: interface adapts to browser size | yes | yes |
| Customisable dashboards | yes | yes |
| UTM licence | VPN licence | |
|---|---|---|
| Languages | German, English | German, English |
| Clientless VPN |
- Browser-based connection via RDP - VNC without additional plug-ins (HTML5) |
- Browser-based connection via RDP - VNC without additional plug-ins (HTML5) |
| SSL VPN clients (OpenVPN) | Download of automatically preconfigured SSL VPN clients | Download of automatically preconfigured SSL VPN clients |
| Wake on LAN | yes | yes |
| Change password | yes | yes |
| Spam management | yes, incl. authorisation system | no |
| Captive Portal | yes, incl. user management | no |
Monitoring, logging and reporting
| UTM licence | VPN licence | |
|---|---|---|
| Log data | yes | yes |
| Anonymisation of log data with regard to GDPR | yes, switched on by default | yes, switched on by default |
| System/services/process status | yes | yes |
| Hardware status | yes | yes |
| Network status | yes | yes |
| Traffic status | yes | yes |
| VPN status | yes | yes |
| User authentication status | yes | yes |
| Live logging | yes | yes |
| Syslog |
- Syslog protocol support - Integrated syslog server |
- Syslog protocol support - Integrated syslog server |
| Syslog logging | Various syslog servers via UDP and TCP | Various syslog servers via UDP and TCP |
| Sensors | for RMM systems | for RMM systems |
| Unified Security Report (USR) | Prepared status reports as a separate service | yes |
| Acute status reports | by mail | no |
| Reports | yes | no |
| Anonymisation of reports | yes | no |
| UTM licence | VPN licence | |
|---|---|---|
| SNMPv1 | yes | yes |
| SNMPv2c | yes | yes |
| SNMPv3 | yes | yes |
| Monitoring of the system status | yes | yes |
| Application status monitoring | yes | yes |
| Monitoring of VPN connection (IPSec, OpenVPN) | yes | yes |
| Monitoring network utilisation | yes | yes |
| Mail queue monitoring | yes | no |
| UTM licence | VPN licence | |
|---|---|---|
| Unified Security Report | yes (optional depending on licence) | yes (optional depending on licence) |
| Visualisation of the security status of devices and services | yes | Not applicable |
| Traffic and security categories | yes | Not applicable |
| Current risk assessments of the individual services | yes | Not applicable |
| Devices, licences, users | yes | Not applicable |
| Performance report of the systems used | yes | Not applicable |
| Risk assessments including recommendations for action | yes | Not applicable |
Network functions
| UTM licence | VPN licence | |
|---|---|---|
| For models (Black Dwarf, Black Dwarf Pro, RC100, RC200) | yes | yes |
| Internet connection via optional LTE USB kit | Internet connection via optional LTE USB kit | Internet connection via optional LTE USB kit |
|
Fallback via optional LTE USB kit | Fallback via optional LTE USB kit | Fallback via optional LTE USB kit |
| UTM licence | VPN licence | |
|---|---|---|
| Virtual WLANs (e.g. guest networks) | yes | yes |
| Authentication via WPA | yes | yes |
|
Authentication via WPA2-Enterprise | yes | yes |
|
Authentication via WPA2-Personal | yes | yes |
|
Authentication via WPA3-Enterprise | yes | yes |
|
Authentication via WPA3-Personal | yes | yes |
|
Authentication via WPA3-OWE | yes | yes |
| WLAN (2,4 or 5 GHz, 802.11 n/ac) | yes | yes |
| WLAN monitoring | yes | yes |
| Encryption WPA2 | yes | yes |
| Encryption WPA3 | yes | yes |
| Channel search | automatically | automatically |
| Number of SSIDs | 2 | 2 |
| UTM licence | VPN licence | |
|---|---|---|
| PPPoE (e.g. for xDSL) | yes | yes |
| DHCP client (e.g. for cable modem) | yes | yes |
| Static IP configuration | yes | yes |
| Load balancing | yes | yes |
| Bandwidth management | yes | yes |
|
Support for dynamic DNS services (free of charge for resellers via www.spdyn.de) | yes | yes |
| Optional LTE / UMTS 2G, 3G, 4G (via LTE USB kit) | yes | yes |
| UTM licence | VPN licence | |
|---|---|---|
| LACP | yes | yes |
Traffic filter function
| UTM licence | VPN licence | |
|---|---|---|
| Time-controlled firewall rules | yes | yes |
| Connection tracking | yes | yes |
| Time-controlled Internet connection | yes | yes |
| Geo IP blocking | yes | yes |
| Packet filter (SPI) and proxy can be combined | yes | Proxy not available |
| Deep Packet Inspection (DPI) | yes | no |
| Content/web filter | yes | no |
| Time-controlled content/web filters | yes | no |
| Supported protocols | All IP-based protocols | All IP-based protocols |
| Predefined rules that apply to the entire system (implicit rules) | yes | yes |
| UTM licence | VPN licence | |
|---|---|---|
| Protection against DoS/DDoS attacks | yes | yes |
| DNS rebinding protection | yes | yes |
| Portscan protection | yes | yes |
| Invalid network packet protection | yes | yes |
| IP blocking in the event of incorrect logon to UTM services (FailToBan) | yes | yes |
| Threat Intelligence Filter - Cloud-based filter for blocking known threats | yes | yes |
| Logging of potentially dangerous connections | yes | yes |
| UTM licence | VPN licence | |
|---|---|---|
| Virus scanner available | yes | no |
| Scan of compressed data, archives (zip etc.) and attachments | yes | Not applicable |
| Automatic updates | yes | Not applicable |
| Availability | in the http/s proxy & mail filter modules | Not applicable |
Mailsecurity
| UTM licence | VPN licence | |
|---|---|---|
| Antispam available | yes | no |
| Configurable filter | yes | not applicable |
| Virus Outbreak Detection | yes | not applicable |
| Virus scanner | yes | not applicable |
| Allow/block lists | yes | not applicable |
| Regular Expressions | yes | not applicable |
| Filter on header fields in emails | yes | not applicable |
| Filter for file attachments | yes | not applicable |
| Filter for SPF/DKIM/DMARC results | yes | not applicable |
| Filter for HTTP links in emails | yes | not applicable |
| Filter on hashes of known emails | yes | not applicable |
| Filter for fake URLs | yes | not applicable |
| URL content filter (blocking of categories such as Danger, Hacking, Pornography etc.) | yes | not applicable |
| Quarantine | yes | not applicable |
| Quarantine with rescan functionality | yes | not applicable |
| Marking the subject of e-mails | yes | not applicable |
| UTM licence | VPN licence | |
|---|---|---|
| Supported protocols | SMTP/S | not applicable |
| Supported STARTTLS | yes | not applicable |
| Authentication |
- Active Directory - LDAP - Local user database - Entra ID | not applicable |
| Check for SPF/DKIM/DMARC | yes | not applicable |
| Check for greeting pause, HELO and reverse DNS | yes | not applicable |
| Protection against recipient flooding"" | yes | not applicable |
| Rate control | yes | not applicable |
| Greylisting with allowlists of e-mail addresses and domains | yes | not applicable |
| Allow-/Blocklists | yes | not applicable |
| E-mail address validation directly via SMTP protocol | yes | not applicable |
| Forcing TLS | yes | not applicable |
| DKIM Signing | yes | not applicable |
| Smarthost with authentication | yes | not applicable |
| UTM licence | VPN licence | |
|---|---|---|
| Supported protocols |
- IMAP/S (external) - POP3/S (external) - SMTP/S (internal) | not applicable |
| Authentication | OAuth2 provider (e.g. for Google Workspace and Microsoft 365) | not applicable |
| UTM licence | VPN licence | |
|---|---|---|
| POP3 proxy available | yes/ transparent | no |
| Supported protocols | POP3 (internal), POP3/S (external) | not applicable |
Web security
| UTM licence | VPN licence | |
|---|---|---|
| HTTP proxy integrated | yes | no |
| Protocols | HTTP & HTTPS | not applicable |
| SNI support | yes | not applicable |
| Transparent mode | HTTP & HTTPS | not applicable |
| Authentication |
- Active Directory (Kerberos, NTLM, Basic-Auth) - LDAP (Basic-Auth) - Local user database (Basic-Auth) - Radius | not applicable |
| URL filter | yes | not applicable |
| Web filter | yes | not applicable |
| Antivirus | yes | not applicable |
| Access control | Profile-based access control based on IP addresses or user groups | not applicable |
| Bandwidth limitation possible | yes | not applicable |
| UTM licence | VPN licence | |
|---|---|---|
| Content & web filter integrated | yes | no |
| Category-based website blocking with over 40 categories | yes | not applicable |
| Scan technology with online database | yes | not applicable |
| Filters |
- URL filter with URL lists - Youth protection incl. BPjM filter - File-Extension/ MIME types filter - Allow/ block lists | not applicable |
| URL shortener | yes | not applicable |
| Advertising blocking | yes | not applicable |
| Force safesearch | yes, in combination with SSL interception | not applicable |
| Threat intelligence feed | yes | not applicable |
| Rules |
- User- / group-specific rules - Time-controlled rules | not applicable |
Further functions
| UTM licence | VPN licence | |
|---|---|---|
| Authentication for all VPN protocols (incl. SSL VPN and HTTP proxy) and UTM filters |
- Active Directory - LDAP - local user database - Entra ID |
- Active Directory - LDAP - local user database - Entra ID |
| Authentication for SSL VPN and HTTP proxy | Radius | Radius |
| UTM licence | VPN licence | |
|---|---|---|
| Configuration | all settings of the UTM firewall | all settings of the UTM firewall |
| Local backup | yes | yes |
| Cloud backup | Automatic and time-based | Automatic and time-based |
| Encryption for cloud backup | yes | yes |
| Restore for cloud backup | Cloud backups can be restored and downloaded via the Unified Security Console (USC) | Cloud backups can be restored and downloaded via the Unified Security Console (USC) |
| UTM licence | VPN licence | |
|---|---|---|
| Integrated one-time password server for highly secure multi-factor authentication (MFA) | yes | yes |
| Procedure | TOTP | TOTP |
| Usable with |
- Admin interface - User interface - SSL VPN - IPsec - SSH |
- Admin interface - User interface - SSL VPN - IPsec - SSH |
| UTM licence | VPN licence | |
|---|---|---|
| Certificate revocation list (CRL) | yes | yes |
| Multi-CA support | yes | yes |
| Multi-host certificate support | yes | yes |
| Let's Encrypt/ ACME | integrated | integrated |
| UTM licence | VPN licence | |
|---|---|---|
| Support for |
- Hyper-V® - VMware® (from version 4.1) - KVM | no |
| UTM licence | VPN licence | |
|---|---|---|
| Reverse proxy integrated | yes | no |
| Usable for | HTTP & HTTPS | not applicable |
| Authentication | Certificate-based | not applicable |
| Loadbalancing | Load balancing on internal servers | not applicable |
| Bandwidth management | yes | not applicable |
| Filters | Various filter options | not applicable |
| Certificate renewal | Automatically through Let's Encrypt/ ACME | not applicable |
| UTM licence | VPN licence | |
|---|---|---|
| Captive portal integrated | yes | no |
| HTTPS certificate | changeable | not applicable |
| Specification of terms of use | yes | not applicable |
| Dynamic rules (packet filter) | yes, for registered users | not applicable |
| Optional user login | yes, with user name and password | not applicable |
| Delegating the user administration | yes, to the user interface | not applicable |
| Design of the captive portal | Customisable | not applicable |
| Multilingual captive portal | yes | not applicable |
VPN functions
| UTM licence | VPN licence | |
|---|---|---|
| Site-to-site (network coupling) | yes | yes |
| End-to-Site/Roadwarrior (connection of individual devices) | yes | yes |
| IKE procedure | IKEv2 and IKEv1 | IKEv2 and IKEv1 |
| Encryption | We support current methods | We support current methods |
| Hash functions | We support current methods | We support current methods |
| Key exchange protocols | Diffie-Hellman (current groups), Eliptic Curve | Diffie-Hellman (current groups), Eliptic Curve |
| Authentication |
- Preshared Keys (PSK) - X.509 certificates - RSA-Keys - MS-CHAPv2 - EAP-TLS |
- Preshared Keys (PSK) - X.509 certificates - RSA-Keys - MS-CHAPv2 - EAP-TLS |
| User authentication |
- Active Directory - LDAP - Local user database - Entra ID |
- Active Directory - LDAP - Local user database - Entra ID |
| Dead Peer Detection (DPD) | yes | yes |
| NAT-T (MOBIKE configurable) | yes | yes |
| Data compression | yes | yes |
| Perfect Forward Secrecy (PFS) | yes | yes |
| Mode | Route- und Policy-Mode VPN | Route- und Policy-Mode VPN |
| UTM licence | VPN licence | |
|---|---|---|
| Site-to-site (network coupling) | yes | yes |
| End-to-Site/Roadwarrior (connection of individual devices) | yes | yes |
| Authentication |
- Active Directory - LDAP - local user database - Entra ID - Radius |
- Active Directory - LDAP - local user database - Entra ID - Radius |
| Encryption | We support current methods | We support current methods |
| Hash functions | We support current methods | We support current methods |
| Mode | Routing mode VPN | Routing mode VPN |
| X.509 certificates | yes | yes |
| TCP/UDP and ports | changeable | changeable |
| Data compression | yes | yes |
| TLS Crypt | yes | yes |
| Export of configurations | possible with end-to-site | possible with end-to-site |
| Securepoint SSL VPN Clients |
- iOS / iPadOS - Android - Windows |
- iOS / iPadOS - Android - Windows |
| UTM licence | VPN licence | |
|---|---|---|
| Site-to-site (network coupling) | yes | yes |
| End-to-Site/Roadwarrior (connection of individual devices) | yes | yes |
| Key exchange | Curve25519 (ECDHE) | Curve25519 (ECDHE) |
| Encryption of user data | ChaCha20 & Poly1305 | ChaCha20 & Poly1305 |
| Hash function | BLAKE2s | BLAKE2s |
| Authentication |
- x25519 key - PSK |
- x25519 key - PSK |
| Mode | Routing mode VPN | Routing mode VPN |
| UDP Port | selectable at will | selectable at will |
| UTM licence | VPN licence | |
|---|---|---|
| Self-service for configuration file | yes (user interface) | yes (user interface) |
| Admin rights required to establish the connection | no | no |
| UTM licence | VPN licence | |
|---|---|---|
| Connection | RDP / VNC over https | RDP / VNC over https |
| Plugin necessary? | No, HTML5 based | No, HTML5 based |
| Authentication |
- Active Directory - LDAP - lokale User-Datenbank - Entra ID - Radius |
- Active Directory - LDAP - lokale User-Datenbank - Entra ID - Radius |
| Encryption | SSL encryption | SSL encryption |
| Access via | User interface | User interface |
Videos zu unseren Firewall Funktionen
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
By submitting, you agree explicitly that data will be transmitted to Vimeo
Our solutions for your company
UTM Firewalls
The basis of network security
- High-end content filter
- Double virus filter
- Anti-spam functions
Antivirus PRO
The antivirus for businesses
- High-performance scan engine
- Fast and unobtrusive
- Central management
Securepoint Mobile Security
MDM and firewall to Go
- Security for smartphone and tablet
- Full mobile device management
- Encrypted connections
Manage mobile devices centrally
With Mobile Device Management
- Control over apps and rights
- For Apple and Android
- Bring your own device (BYOD)
Reliable data backup
With Unified Backup
- The last protection against ransomware
- Reliable, fast, up-to-date
- Server in Germany
Cyber-Awareness-Training
With Awareness PLUS
- Makes employees a "human firewall
- Regular IT security training
- Measurable learning success
